LZM water-based acrylic topcoat (self-drying).
1. Product Overview:
- ◆ Category: The product is a one-component self-drying paint with high-grade acrylic resin as the film-forming substance;
- ◆ Composition: high-grade resin, pigment, filler, additives, water, etc.;
- ◆ Features:
- ※This product uses water as the dispersion medium, no ignition point at room temperature, no combustion and no explosion;
- ※There are no toxic and harmful substances in the construction process and the coating film forming process, which is in line with environmental protection requirements and EU RoHs directives;
- ※It has excellent adhesion, weather resistance and protective decoration properties;
- ※Because the volatility of water is less than that of organic solvents, the construction area is larger than that of oil-based paint under the same construction thickness.
2. Scope of application: It is suitable for all kinds of light industrial products, electromechanical, instruments, vehicles and other metal surfaces.
3. Technical indicators (typical data).
| Projects |
Indicators |
| Color and appearance |
Viscous liquids of all colors |
| Fineness |
≤20μm |
| Viscosity (coated - 4 cups). |
≥ 60 seconds |
| Solids content (120°C/2 hours). |
≥40% |
| Adhesion (circle method). |
≤ level 1 |
| Impact strength |
≥50 cm.kg |
| Pencil hardness |
≥HB |
| Flexibility |
≤1 mm |
| Water resistance (tap water). |
Does not blister for 96 hours, does not fall off, and allows for slight discoloration |
| Salt water resistance (3% NaCl solution). |
It does not blister for 48 hours, does not fall off, and allows for slight discoloration |
| Drying time (23±2°C, relative humidity ≤80%) |
Surface dry ≤ 40 minutes/dry ≤ 48 hours/hard dry ≤ 7 days |
(Note: The test conditions for salt water and salt spray resistance are: 1. Substrate: cold-rolled steel plate with degreasing and grinding; 2. Coating: spray epoxy zinc-rich primer
twice + painted twice in epoxy micaceous iron; 3. Drying: Drying at room temperature for seven days. )
Fourth, the construction reference:
- ◆Surface treatment: Safely remove impurities such as floating ash, floating rust, oil stain on the surface of the workpiece to be painted, so that the surface of the workpiece to be painted is clean and dry;
- ◆ Construction method: spraying or brushing, soft wool brush should be used when brushing;
- ◆ Thinner: Purified water or clean tap water;
- ◆ Dilution ratio: add water according to 5%~15% of the weight of the original paint, or adjust the appropriate amount according to the specific situation;
- ◆ Construction viscosity: spraying viscosity: 25~30 seconds (coating -4 cups, 23±2 °C);
- ◆ Drying method: natural drying at room temperature, or baking at low temperature 80°C~90°C for 15~20 minutes;
- ◆Coating thickness: single-layer dry film thickness 15μm ~ 25μm.
5. Precautions:
- ◆The quality of metal substrate treatment will directly affect the final effect and protective performance of the coating film;
- ◆ The substrate must be coated as soon as possible after treatment, and the secondary coating can be carried out after the paint film is dry;
- ◆ Construction cannot be done when the temperature is lower than 5 °C and the relative humidity ≥ 85%;
- ◆ Outdoor construction can not be done on rainy days, if it has been constructed, it is necessary to cover it with a tarpaulin to protect the paint film that is not completely dry;
- ◆This product should be stored in a cool and ventilated place at a temperature of 5°C~45°C, and the validity period is one year; If the storage period is exceeded, it can still be used after passing the inspection.
6. Packing and Shipping:
- ◆ Packing: 20kg/barrel;
- ◆ Transportation: Transported as non-dangerous goods.
div class="portfolio__details-text mb-40">
LZD water-based acrylic primer (self-drying).
1. Product Overview:
- ◆ Category: The product is a one-component self-drying paint with high-grade resin as the film-forming substance;
- ◆ Composition: high-grade resin, pigment, filler, additives, water, etc.;
- ◆ Features:
- ※This product uses water as the dispersion medium, no ignition point at room temperature, no combustion and no explosion;
- ※There are no toxic and harmful substances in the construction process and the coating film forming process, which is in line with environmental protection requirements and EU RoHs directives;
- ※It has excellent adhesion, grinding resistance, rust resistance and matching properties with most water-based and oil-based topcoats;
2. Scope of application: It is suitable for all kinds of light industrial products, electromechanical, instruments, vehicles and other metal surfaces.
3. Technical indicators (typical data).
| Projects |
Indicators |
| Color and appearance |
Viscous liquids of all colors |
| Fineness |
≤50μm |
| Viscosity (coated - 4 cups). |
≥ 80 seconds |
| Solids content (120°C/2 hours). |
≥50% |
| Adhesion (circle method). |
≤ level 1 |
| Impact strength |
≥50 cm.kg |
| Pencil hardness |
≥HB |
| Flexibility |
≤1 mm |
| Water resistance (tap water). |
Does not blister for 96 hours, does not fall off, and allows for slight discoloration |
| Salt water resistance (3% NaCl solution). |
It does not blister for 48 hours, does not fall off, and allows for slight discoloration |
| Drying time (23±2°C, relative humidity ≤80%) |
Surface dry≤ 30 minutes/dry ≤ 48 hours/hard dry≤ 7 days |
(Note: The test conditions for salt water and salt spray resistance are: 1. Substrate: cold-rolled steel plate with degreasing and grinding; 2. Coating: spray epoxy zinc-rich primer twice + paint twice in epoxy micaceous; 3. Drying: Drying at room temperature for seven days. )
Fourth, the construction reference:
- ◆Surface treatment: Safely remove impurities such as floating ash, floating rust, oil stain on the surface of the workpiece to be painted, so that the surface of the workpiece to be painted is clean and dry;
- ◆ Construction method: spraying or brushing, soft wool brush should be used when brushing;
- ◆ Thinner: Purified water or clean tap water;
- ◆ Dilution ratio: add water according to 5%~15% of the weight of the original paint, or adjust the appropriate amount according to the specific situation, the maximum amount should not exceed 25%;
- ◆ Construction viscosity: spraying viscosity: 25~35 seconds / brushing viscosity: 50~60 seconds (coating - 4 cups, 23±2 °C);
- ◆ Drying method: natural drying at room temperature, or baking at low temperature 80°C~90°C for 15~20 minutes;
- ◆Coating thickness: single-layer dry film thickness 15μm ~ 25μm;
5. Precautions:
- ◆The quality of metal substrate treatment will directly affect the final effect and protective performance of the coating film;
- ◆ The substrate must be coated as soon as possible after treatment, and the secondary coating can be carried out after the paint film is dry;
- ◆ Construction cannot be done when the temperature is lower than 5 °C and the relative humidity ≥ 85%;
- ◆ Outdoor construction can not be done on rainy days, if it has been constructed, it is necessary to cover it with a tarpaulin to protect the paint film that is not completely dry;
- ◆This product should be stored in a cool and ventilated place at a temperature of 5°C~45°C, and the validity period is one year; If the storage period is exceeded, it can still be used after passing the inspection.
6. Packing and Shipping:
- ◆ Packing: 25kg/barrel
- ◆ Transportation: Transported as non-dangerous goods.
；
LZD&M water-based acrylic underside in one paint (self-drying).
1. Product Overview:
- ◆ Category: The product is a one-component self-drying paint with high-grade resin as the film-forming substance;
- ◆ Composition: high-grade resin, pigment, filler, additives, water, etc.;
- ◆ Features:
- ※This product uses water as the dispersion medium, no ignition point at room temperature, no combustion and no explosion;
- ※There are no toxic and harmful substances in the construction process and the coating film forming process, which is in line with environmental protection requirements and EU RoHs directives;
- ※It has excellent adhesion, weather resistance, and anti-rust performance;
2. Scope of application: It is suitable for all kinds of light industrial products, electromechanical, instruments, vehicles and other metal surfaces.
3. Technical indicators (typical data).
| Projects |
Indicators |
| Color and appearance |
Viscous liquids of all colors |
| Fineness |
≤25μm |
| Viscosity (coated - 4 cups). |
≥ 80 seconds |
| Solids content (120°C/2 hours). |
≥30% |
| Adhesion (circle method). |
≤ level 1 |
| Impact strength |
≥50 cm.kg |
| Pencil hardness |
≥HB |
| Flexibility |
≤1 mm |
| Water resistance (tap water). |
Does not blister for 96 hours, does not fall off, and allows for slight discoloration |
| Salt water resistance (3% NaCl solution). |
It does not blister for 48 hours, does not fall off, and allows for slight discoloration |
| Drying time (23±2°C, relative humidity ≤80%) |
Surface dry≤ 30 minutes/dry ≤ 48 hours/hard dry≤ 7 days |
Note: The test conditions for salt water and salt spray resistance are: 1. Substrate: cold-rolled steel plate with degreasing and grinding; 2. Coating: spray epoxy zinc-rich primer twice + paint twice in epoxy micaceous; 3. Drying: Drying at room temperature for seven days. )
Fourth, the construction reference:
- ◆Surface treatment: Safely remove impurities such as floating ash, floating rust, oil stain on the surface of the workpiece to be painted, so that the surface of the workpiece to be coated is clean and dry;
- ◆ Construction method: spraying or brushing, soft wool brush should be used when brushing;
- ◆ Thinner: Purified water or clean tap water;
- ◆ Dilution ratio: add water according to 5%~15% of the weight of the original paint, or adjust the appropriate amount according to the specific situation, the maximum amount should not exceed 25%;
- ◆ Construction viscosity: spraying viscosity: 20~25 seconds / brushing viscosity: 50~60 seconds (coating -4 cups, 23±2 °C);
- ◆ Drying method: natural drying at room temperature, or baking at low temperature 80°C~90°C for 15~20 minutes;
- ◆Coating thickness: single-layer dry film thickness 10μm ~ 20μm;
- ◆Coating area: 6-8m2/kg for two coatings, the specific consumption depends on the roughness of the coated surface, the substrate material and the construction method.
5. Precautions:
- ◆The quality of metal substrate treatment will directly affect the final effect and protective performance of the coating film;
- ◆ The substrate must be coated as soon as possible after treatment, and the secondary coating can be carried out after the paint film is dry;
- ◆ Construction cannot be done when the temperature is lower than 5 °C and the relative humidity ≥ 85%;
- ◆ Outdoor construction can not be done on rainy days, if it has been constructed, it is necessary to cover it with a tarpaulin to protect the paint film that is not completely dry;
- ◆This product should be stored in a cool and ventilated place at a temperature of 5°C~45°C, and the validity period is one year; If the storage period is exceeded, it can still be used after passing the inspection.
6. Packing and Shipping:
- ◆ Packing: 20kg/barrel;
- ◆ Transportation: Transported as non-dangerous goods.
LZM water-based acrylic topcoat (drying).
1. Product Overview:
- ◆Category: The product is a one-component drying paint with high-grade resin as the film-forming substance;
- ◆ Composition: high-grade resin, pigment, filler, additives, water, etc.;
- ◆ Features:
- ※This product uses water as the dispersion medium, no ignition point at room temperature, no combustion and no explosion;
- ※It has excellent adhesion, weather resistance and protective decoration properties;
- ※Because the volatility of water is less than that of organic solvents, the construction area is larger than that of oil-based paint under the same construction thickness;
- ※There are no toxic and harmful substances in the construction process and the coating film forming process, which is in line with environmental protection requirements and EU RoHs directives;
2. Scope of application: It is suitable for all kinds of light industrial products, electromechanical, instruments, vehicles and other metal surfaces.
3. Technical indicators (typical data).
| Projects |
Indicators |
| Color and appearance |
Viscous liquids of all colors |
| Fineness |
≤20μm |
| PH value |
8.0~9.0 |
| Viscosity (coated - 4 cups). |
≥ 45 seconds |
| Solids content (120°C/2 hours). |
≥35% |
| Gloss (60° light meter). |
0~90 |
| Adhesion (circle method). |
≤ level 1 |
| Impact strength |
≥50 cm.kg |
| Pencil hardness |
≥2H |
| Flexibility |
≤1 mm |
| Salt water resistance (3% NaCl solution). |
(Single-layer paint film) does not bubble and does not fall off for 120 hours |
| Salt spray resistance (neutral salt spray test). |
(Single-layer paint film) does not bubble and does not fall off for 96 hours |
| Alcohol wiping resistance (30 wipes back and forth). |
I do not fade |
(Note: The test conditions for salt water and salt spray resistance are: 1. Substrate: cold-rolled steel plate with degreasing and grinding; 2. Coating: spraying, dry film 20μm ~ 25μm; 3. Drying: Bake at 145±2°C for 30 minutes. )
Fourth, the construction reference:
- ◆Surface treatment: Safely remove impurities such as floating ash, floating rust, oil stain on the surface of the workpiece to be painted, so that the surface of the workpiece to be painted is clean and dry;
- ◆ Construction method: spraying or brushing, soft wool brush should be used when brushing;
- ◆ Thinner: Purified water or clean tap water;
- ◆ Dilution ratio: add water according to 10%~25% of the weight of the original paint, or adjust the appropriate amount according to the specific situation;
- ◆ Construction viscosity: spraying viscosity: 25~30 seconds (coating -4 cups, 23±2 °C);
- ◆ Drying method: 145±2°C (low temperature type) / 175±2°C (high temperature type), bake at constant temperature for 30 minutes;
- ◆Coating thickness: single-layer dry film thickness 15μm ~ 25μm.
5. Precautions:
- ◆The quality of metal substrate treatment will directly affect the final effect and protective performance of the coating film;
- ◆ The coated workpiece should stand in a dust-free environment for 3~8 minutes before entering the baking equipment;
- ◆This product should be stored in a cool and ventilated place at a temperature of 0°C~45°C, and the validity period is one year; If the storage period is exceeded, it can still be used after passing the inspection.
6. Packing and Shipping:
- ◆ Packing: 20kg/barrel;
- ◆ Transportation: Transported as non-dangerous goods.
